Overview
The GF-130G is a premium coated paper shipping and carton label, specifically engineered for the logistics, warehousing, and distribution sector. This label features a high-quality semi-gloss white coated face stock paired with a robust permanent adhesive, delivering excellent printability and reliable performance in demanding industrial environments. Ideal for applications requiring clear identification, vibrant graphics, and secure adhesion on various packaging surfaces.
Features
Premium Coated Paper Face Stock: 80g high whiteness (92%) paper with medium gloss (65%), suitable for high-quality printing (offset, flexo, etc.).
Universal Hot Melt Adhesive: Provides permanent adhesion for damp surfaces, with good low-temperature performance (service temp -20℃ to 70℃). Minimum application temp: 10℃. Not recommended for PVC, severely curved, rough, or corrugated surfaces.
Glassine Release Liner: 57g white transparent glassine, suitable for roll materials and automatic photoelectric labeling systems.
Storage & Shelf Life: Avoid prolonged exposure >50℃ and direct sunlight. 1-year shelf life under standard conditions (23±2℃, 50±5% RH). Prior testing is recommended.
Application
Shipping Labels for Cartons and Pallets
Warehouse Inventory and Bin Labels
Logistics and Distribution Center Labeling
Industrial Product Identification
Promotional and Color-Coded Labels on Packaging
Optimal Printing Solutions
1.Recommended Ribbons:
Wax Resin Thermal Transfer Ribbons
Model:TR4021 Wax Resin Ribbonhttps://www.dggaofe.com/Industrial-Grade-Wax-Resin-for-Durable-Labeling-pd535773948.html
Features:Delivers ≥2.0 ODR high-density printing for sharp barcodes, text, and graphics on coated paper.
Maintains print quality at 300 mm/s (12 ips) enabling efficient high-speed production.
Wax-resin hybrid formulation provides reliable adhesion on coated paper with 80°C heat resistance.
2.Recommended Printers:
Model:TSC 342pro Printer
Features:Industrial 300 DPI Resolution delivers high-precision printing for detailed barcodes and graphics.
Dual-Motor Durability extends printer lifespan while maintaining 76 mm/s print speed.
Expandable 4GB SD Storage supports large label formats and complex print jobs.
Other Option
| No. | Type | Model |
| 1 | Cost-effective coated paper labels | GF-131G |
| 2 | High-quality writing paper labels on yellow background | GF-136G |
| 3 | 120g coated paper labels | GF-139G |
| 4 | 160g strong adhesive coated paper label | GF-140G |
| 5 | Water-gel coated paper label | GF-132G |
| 6 | Double coated paper label | GF-133G |
| 7 | Removable coated paper label | GF-134G |
| 8 | Bright (mirror) coated paper label | GF-135G |
| 9 | Writing paper labels | GF-137G |
Specification
| Category | Parameter | Value / Description |
| Face Stock | Type | Semi-Gloss White Coated Paper |
| Basis Weight | 80 g/m² ±10% (ISO 536) |
| Thickness | 0.072 mm ±10% (ISO 534) |
| Adhesive | Type | Permanent Rubber-Based |
| Initial Tack (FTM9, st/st) | 17.0 N/25mm (or tear) |
| Peel Adhesion @ 20 min (FTM2, st/st) | 5.0 N/25mm |
| Peel Adhesion @ 24 hrs (FTM2, st/st) | 11.0 N/25mm |
| Min. Application Temperature | +10°C |
| Service Temperature Range | -15°C to +65°C |
| Compliance | Suitable for Indirect Food Contact (FDA 175.105) |
| Liner | Type | White Glassine |
| Basis Weight | 61 g/m² ±10% (ISO 536) |
| Thickness | 0.055 mm ±10% (ISO 534) |
| Performance | Print Compatibility | Thermal Transfer, Flexographic, Offset, Letterpress, Dot Matrix |
| Primary Color | White |
| Shelf Life | 1 year at 23±2°C & 50±5% RH |
| Not Recommended For | PVC Substrates |
