Overview
GF-131G Coated Paper Barcode and QR Code Labels are designed for Asset Identification and Tracking applications that require clear print quality, reliable adhesion, and cost-effective performance.
Using a high-whiteness coated paper face stock combined with a permanent hot melt adhesive, this label solution ensures accurate barcode and QR code readability throughout the asset lifecycle, even in humid or low-temperature environments.
Features
Excellent Printability for Accurate Data Capture
The coated paper surface delivers high contrast and sharp definition, ensuring barcodes and QR codes remain readable for scanners and mobile devices.
It supports multiple printing technologies, making it suitable for large-scale asset labeling projects.
Compatible with flexographic, offset, letterpress, gravure, and screen printing
Ideal for high-density barcodes and QR codes
Smooth surface for fine text and graphics
Reliable Permanent Hot Melt Adhesive
GF-131G uses a general-purpose permanent hot melt adhesive that provides strong initial tack and stable peel strength.
Secure adhesion on common asset surfaces
Performs well in humid environments
Maintains bonding performance at low temperatures after application
This makes it suitable for long-term asset identification where labels must remain firmly attached during handling, storage, and transport.
Wide Temperature Performance Range
Designed for operational flexibility in asset tracking systems:
This allows consistent labeling performance across warehouses, factories, and logistics environments.
Application
GF-131G Barcode and QR Code Labels are widely used in:
Fixed asset identification
Equipment and tool tracking
Warehouse asset management
IT and electronics asset labeling
Logistics and inventory tracking systems
They provide a cost-efficient solution for assets requiring clear identification and traceability, without the need for specialty films.
Optimal Printing Solutions
1.Recommended Ribbons:
Resin Thermal Transfer Ribbons
Model:TR4021 Wax Resin Ribbon(https://www.dggaofe.com/Industrial-Grade-Wax-Resin-for-Durable-Labeling-pd535773948.html)
Features:
Low-energy, high-speed printing up to 12 IPS
Sharp and durable barcodes for asset tracking
Optimized for coated paper labels like GF-131G
2.Recommended Printers:
Model:TSC MH641 Printer
Features:
It delivers high-resolution printing at 24 dots/mm (600 DPI) for detailed barcode and label output.
Built with an aluminum alloy chassis and large viewing window, it withstands demanding industrial environments.
The printer supports expandable memory via microSD (up to 32GB) and offers Ethernet, USB, and optional wireless connectivity.
Other Option
| No. | Type | Model |
| 1 | 120g coated paper labels | GF-139G |
| 2 | 160g strong adhesive coated paper labels | GF-140G |
| 3 | strong adhesive yellow liner coated paper labels | GF-141G |
Specification
| MATERIAL NAME | GF-131G coated paper label |
| Surface material weight | 80±3 g/㎡ ISO536 |
| Surface material thickness | 70±3 um ISO534 |
| Surface material whiteness | 92% ISO2470/1 |
| Surface gloss | 65% HUNTER 75° |
| Adhesive | General-purpose permanent hot melt adhesives (hot melt glues) |
| Initial tack (minimum) | 21N/25mm FTM 9 |
| 90° peel force | 8N/25mm FTM 2 |
| Minimum labeling temperature | 10℃ |
| Temperature range | - 20 - 70℃ |
| Base paper | Glassine paper |
| Base paper weight | 57g/㎡ ISO536 |
| Base paper thickness | 51um ISO534 |
| Printability |
| Features: Flexographic printing, offset printing, letterpress printing, gravure printing, and screen printing. Suitable for fine printing requirements. Testing is recommended before use. |
| Storage and preservation |
| Avoid prolonged exposure to environments above 50℃ or direct sunlight during storage. The shelf life is one year at a temperature of 23±2℃ and a relative humidity of 50±5%. Products past their expiration date can still be used if they pass inspection. |
