B-363G
GAOFE
The B-363G is a high-performance, industrial-grade synthetic paper label engineered for the rigorous demands of Logistics, Warehousing, and Distribution. As part of our Shipping and Carton Labels category, it is constructed from PG56 Synthetic Resin Paper, a tear-proof and water-resistant material designed to ensure critical shipping information remains intact and legible throughout the entire supply chain, even in challenging environmental conditions.
Extreme Durability: Made from tear-resistant and waterproof synthetic paper, ensuring labels do not rip, smudge, or degrade from moisture, abrasion, or frequent handling.
All-Weather Performance: Excellent weather and solvent resistance for reliable performance both indoors and outdoors.
Strong Adhesion: Features a permanent acrylic adhesive with high initial tack and holding power, providing a secure bond to a variety of carton surfaces.
Superior Printability: A smooth, white surface offers excellent contrast and sharp print quality for barcodes, text, and graphics using thermal transfer printing.
Clean Die-Cutting: Engineered for precise and clean die-cutting, ensuring smooth label dispensing and application.
.
Ideal for permanent identification and tracking where durability is paramount:
Master Carton and Pallet Labels
Outdoor Shipping Labels
Long-Term Inventory and Asset Tags in Warehouses
Compliance and Bill of Lading Labels
Logistics and Distribution Center Routing Labels
Wax Resin Ribbon
· Model: TR4023
· Features:
This wax-resin ribbon provides excellent adhesion to synthetic materials, creating a durable, scratch-resistant, and water-resistant print that is ideal for long-lasting serial numbers.
High-Resolution Industrial Printer
· Model: TSC X610 (600dpi)
· Features:
·This high-resolution printer delivers crisp, precise text and barcodes essential for clear serial number identification. Its reliability and print quality are perfectly suited for industrial labeling tasks.
Other Options
| NO. | Name | Model | Color |
| 1 | Cryogenic Nylon label | B-364G | White |
| 2 | Blood bag label | B-375G | White |
| 3 | Cable synthetic label | B-678G | White |
Specification
| Category | Attribute | Specification / Value |
|---|---|---|
| Surface Material | Name / Type | Synthetic Paper (Synthetic Film) |
| Thickness | 0.056 mm ± 0.005 mm | |
| Basis Weight | 47 g/m² ± 4 g/m² | |
| Color | White | |
| Smoothness | Excellent | |
| Printability | Excellent | |
| Die-Cutting Performance | Excellent | |
| Adhesive | Type | Permanent Acrylic |
| Thickness (Coating) | 0.018 mm ± 0.002 mm | |
| Dry Coating Weight | 18 g/m² ± 2 g/m² | |
| Initial Tack (Ball No.) | ≥ 4 | |
| Adhesion Strength (180° Peel) | ≥ 0.8 kgf/inch | |
| Release Force | 10 gf/inch ± 5 gf/inch | |
| Holding Power | ≥ 24 hr/kg×inch | |
| Temperature Range | 0°C to 100°C | |
| Release Liner | Name / Type | PE Coated Release Paper |
| Thickness | 0.068 mm ± 0.005 mm | |
| Basis Weight | 80 g/m² ± 2 g/m² | |
| Color | White | |
| Smoothness | Excellent | |
| Performance | Weather Resistance | Excellent |
| Solvent Retention | ≤ 2.0% | |
| General | Product Code | B-363G |
| Full Material Construction | Synthetic Film / Acrylic Adhesive / PE Liner | |
| Storage Life | 12 Months | |
| Storage Conditions | Cool, Ventilated, Avoid Direct Sunlight |
