Overview
Model: B-205G Polyimide Film Adhesive Tape
A premium-grade high-temperature resistant tape designed for demanding electronics and PCB manufacturing applications. Made with polyimide film (Kapton®-like material) and silicone adhesive, it ensures reliable insulation, solder masking, and component protection in extreme conditions (up to 260°C).
✔ Ideal for:
Wave/reflow soldering masking (prevents solder splatter on PCBs)
Gold finger protection (anti-oxidation during plating)
Transformer/capacitor insulation (dielectric strength: 4.8 kV)
SMT component fixation (strong adhesion, no residue after heat exposure)
Features
✅ High-Temperature Resistance – Withstands 260°C for 30 mins without adhesive residue (critical for lead-free soldering).
✅ Strong Adhesion (4.5 N/25mm) – Secures components during PCB assembly without peeling.
✅ No Residue & Solvent-Resistant – Clean removal after flux exposure, ideal for post-soldering cleaning.
✅ Electrical Insulation – 4.8 kV dielectric strength, perfect for high-voltage PCB insulation.
✅ Tensile Strength (90 N/25mm) – Durable for FPC alignment and battery cell stacking.
(Material: Polyimide film (0.025mm) + Silicone adhesive)
Application
1. PCB Manufacturing
2. Electronic Component Insulation
3. Automotive & Aerospace Electronics
Other Options
For different thickness & adhesion needs, consider: B-205G,B-208G,B-211G,B-215G
Specification
| Property | Value |
| Total Thickness | 0.05±0.002 mm |
| Adhesion | 4.5±0.5 N/25mm |
| Voltage Resistance | 4.8 kV |
| Tensile Strength | 90 N/25mm |
| Heat Resistance | 260°C/30 mins (no residue) |
Material: Polyimide type
Thickness: 0.055mm ,0.075mm,0.1mm,0.125mm,0.15mm
Material Model: B-205G,B-208G,B-211G,B-213G,B-215G
Color: brown
Label Properties: Heat Resistant up to 300 degree, Electronic insulation
