Overview
Model B-236G is a high-security anti-counterfeit tamper-evident label with hologram full transfer technology. It leaves irreversible "VOID" marks once peeled off, and the holographic layer is fully transferred to the surface. Supporting customized printing of logos, serial numbers, barcodes and texts, it delivers reliable brand protection and tamper evidence, widely used for packaging seals, electronics, cosmetics, pharmaceuticals and luxury goods.
Specification
Product Structure | Material | Weight | Thickness | Color |
Printable Coating Layer | Surface Treatment Coating | 1±0.5g/㎡ | 1um±0.5um | Transparent |
PET | 25um PET (Laser VOID) | 38±1.5g/㎡ | 28±2um | Silver |
Adhesive Layer | Acrylic Pressure-sensitive Adhesive | 15±1.5g/㎡ | 15±2um | Transparent |
Release Paper | White Glassine Release Paper | 80±3g/㎡ | 70±2um | White |
Product properties
Test Item | Testing Equipment | Testing Method | Test Value Standard Range |
Peel Force of Pressure-sensitive Adhesive | 180° Micro-control Tensile Testing Machine | GB/T 2792-2014 | ≥6N/in |
Initial Tack of Pressure-sensitive Adhesive | 30° Steel Ball Sliding Testing Machine | GB/T 4852-2002 | ≥Steel Ball No. 5 |
Holding Force of Pressure-sensitive Adhesive | Normal Temperature Holding Force Testing Machine | GB/T 4851 | ＞24H |
Release Force of Release Paper | 180° Micro-control Tensile Testing Machine | GB/T 2792-2014 | 3 - 20g |
Stripping and Display Effect of the Attached Object | 180° Micro-control Tensile Testing Machine | Visual Inspection | Laser VOID Character Pattern |
