B-674G
GAOFE
The B-674G is a premium white cable wrap label engineered specifically for electronics and electrical applications where durability and clarity are paramount. As a key product within the Wire and Cable Identification Labels category, this cable wrap label is constructed from a high-performance transparent vinyl film with a durable acrylic adhesive. It features a blank white thermal transfer printing area and a protective overlay film, making it the ideal solution for creating permanent, legible identifications that withstand challenging environments.
Superior Durability: Excellent resistance to water, oils, fuels, and common chemicals.
High-Temperature & Weather Resistant: Stable performance across a wide temperature range (-40°C to 70°C) and resistant to humidity and UV aging.
Excellent Adhesion: Strong initial tack and high ultimate adhesion to stainless steel and cable surfaces.
Optical Clarity: High light transmittance (90%) ensures the underlying cable color remains visible for quick visual inspection.
Flame Retardant: Meets industry standards with a short average burn time for enhanced safety.
Electrical Insulation: High dielectric strength (6000V) provides an added layer of protection.
Application
Ideal for permanent identification and asset management in demanding indoor and outdoor settings:
Industrial control panels and machinery wiring
Data center and network cabling
Telecommunications infrastructure
Automotive and aerospace wiring harnesses
Utility and power distribution systems
Any environment requiring labels resistant to abrasion, moisture, and chemicals
Recommended Ribbon
Model: TR4510B Resin Ribbonhttps://www.dggaofe.com/GAOFE-TR4510B-Resin-Ribbon-for-High-Temperature-Labels-Durable-Printing-Solution-pd519083948.html
Why: High abrasion resistance, alcohol-proof, and compatible with various types of labels. Ideal for harsh conditions.
Recommended Printer
Model: CAB EOS2/300dpihttps://www.dggaofe.com/CAB-EOS2-Industrial-Label-Printer-Shrink-Tube-Barcode-Printing-pd529467648.html
Why: Precision 300dpi output for fine text/barcodes; supports wrap-label formats.
| NO. | Name | Model |
| 1 | Fold cable label | B-678G |
Constitute
Specification
physical characteristics | test method | Average test results |
thickness | ASTM D1000 Testing -Vinyl substrate -Pressure-sensitive adhesive -Off-form paper -amount to | 0.06 mm 0.023 mm 0.074 mm 0.16 mm |
Paste to: -stainless steel | ASTM D1000 Testing Paste for 20 minutes Stick for 24 hours | ≥1900gf/inch ≥2000gf/inch |
-Initial adhesion -Hold adhesion | ASTM D2979 Testing ASTM D3654 Testing | 430g 310g(18.7oz) |
-light transmittance | ISO7686:2005 | 90% |
-fog level | ISO7686:2005 | 45% |
insulativity | ASTM D1000 Testing | 6000V |
inflammability | ASTM D1000 Testing Average burning time | Less than 10 seconds |
Function test method:
Use TR4510B series black color strip heat transfer printing sample tape.
function | test method | test result |
Maximum adaptation temperature | 70°C for 30 days | has/have no influence |
Maximum adaptation temperature | -40°C for 30 days | has/have no influence |
Moisture resistance | 37 ° C (100 ° F), relative humidity 95% for 30 days | has/have no influence |
ageing resistance | 30 days xenon arc aging test machine, one cycle | has/have no influence |
Chemical test
chemical reagent | Visual observation affects | |
Base material/adhesive | carbon tape | |
Cleaners and solvents | ||
isopropanol | No visible effects | No visible effects |
mineral spirits | No visible effects | No visible effects |
Northwoods TM Buzz Saw Terpene Cleaner | No visible effects | No visible effects |
deionized water | No visible effects | No visible effects |
Fuel, oil and lubricants | ||
gasoline | Slight lifting | No visible effects |
brake fluid | No visible effects | No visible effects |
SAE 30 WT Oil at 70°C | No visible effects | No visible effects |
Yellow 77 Lubricating oil | No visible effects | No visible effects |
Aerospace liquids | ||
JP-8, space fuel | No visible effects | No visible effects |
Skydro 500B-4 | Material damage | NA |
MIL-H-5606 | No visible effects | No visible effects |
Unless otherwise noted, tests are performed after 24 hours at room temperature. The test consists of five cycles, soaking in the specified test fluid for 10 minutes, then removing and placing for 30 minutes before testing. B-674G is not recommended for use in harsh organic solvents such as methyl ethyl ketone, acetone, or 1,1,1-trichloroethane.
Term of validity
The product can be stored for at least 1 year (from the date of receipt) in an unopened environment with room temperature 15 ° C-23 ° C and relative humidity 60%.
